Product Parameters
Product model | ANACE1-230V/32A | ANACE1-400V/32A |
Input power connection | L +N + PE | 3Ph + N + PE（L1, L2, L3, N, PE） |
AC input voltage | 230 VAC ± 10% | 400 VAC ± 10%
|
AC input frequency
| 50/60 Hz
| 50/60 Hz
|
Rated operating current
| 32 A
| 32 A （3P）
|
Charging connector
| Type 2
| Type 2(3P)
|
Rated power
| 7.3 kW
| 22 kW |
| Over-voltage protection | 253 VAC |
| Input under-voltage protection | 207 VAC |
| Output over current protection | 35.2 A |
| Leak current protection |
|
| Cable length | Nominal 3.5 meters |
| HMI | 4.3 inch LCD Touchscreen |
| Signal indicator |
| Standby | steady white light |
| Plug in | steady purple |
| Charging | shining blue light |
| Charging completed | steady green light |
| Alarming | steady red light |
| Safety standards | IEC 61851 |
| Back-end Communication protocol | OCPP 1.6 |
| RFID system RFID | ISO 14443A, MIFARE DESFire Ev1 |
| Internet connection | 4G 、Ethernet、Wi-Fi (optional) |
| Energy meter | EU MID Approved Energy meter |
| Certification | CE |
| Dimension | 285*150*410mm（W*D*H） |
| Weight | 8kg |
Features for the Electric Car Charging Station
| Features | Description |
| Innovation | Built with high-quality PC+ABS housing, this Electric Car Charging Station ensures reliable performance in temperatures from -30°C to +55°C. |
| Flexibility | Supports global standards (IEC 61851, OCPP 1.6) with both 230V and 400V input, making it suitable for varied EV and battery needs in residential and commercial settings. |
| Scalability | Available in 7kW and 22kW power options, the Electric Car Charging Station can be installed in all capacities including home garages and large parking facilities for uniform installations. |
| Low Maintenance | Features remote diagnostics, 24/7 support, and an EU MID-approved meter for accurate monitoring, ensuring minimal upkeep requirements. |
| Ease of Use | Equipped with a 4.3-inch LCD touchscreen, the Electric Car Charging Station offers an intuitive interface with visual status indicators for seamless operation. |
| Smart Charging Intelligence | Integrated smart charging algorithms optimize charging times, balance load efficiently, and support real-time remote management for smart energy use. |
| Customization | Supports RFID access (ISO 14443A, MIFARE DESFire Ev1) and flexible connectivity options, tailored to meet specific user requirements. |
| Robust Connectivity | 4G, Wi-Fi, and Ethernet options allow seamless integration with backend systems for secure payment processing and energy management, ideal for managing multiple charging locations. |
