Dual 22kW Output
Simultaneous fast charging for two EVs
Multiple Access Modes
Supports RFID, QR code, app, plug & charge
OCPP 1.6J Compatible
Easy integration with backend platforms
Built-in Protection
Full electrical safety including surge, overheat, and leakage
Rugged Outdoor Design
IP55, galvanized steel, wide climate tolerance
4G/WiFi/Ethernet Connectivity
Flexible networking for remote control and monitoring
Smart Charging Access
Flexible control options for all users
This charger supports a range of user authentication and charging start methods to meet various operational scenarios. Standard features include plug & charge and RFID card swipe, while optional features such as QR code scanning and mobile app access bring added flexibility and convenience. These access modes make it ideal for use in public parking lots, fleet depots, and residential communities. Integration with mobile platforms enables real-time control and energy monitoring, while maintaining a user-friendly interface for EV drivers.
Durability Meets Safety
Reliable performance in any environment
Built with galvanized steel housing and an IP55 rating, this charger is engineered for long-lasting outdoor use. It can operate from -30°C to +55°C, making it suitable for harsh climates. Internal protections include overvoltage, undervoltage, overload, overheating, and emergency stop functions. The unit also integrates a Type A RCD and MID-certified metering, ensuring compliance with international standards for electrical safety and billing accuracy. Ideal for commercial operators who prioritize safety and uptime.
Model No.
| FLOOR-STANDING AC CHARGER |
Enclosure Material
| Galvanized Steel Sheet |
| Input Power | L+N+PE(single-phase)、50/60 Hz | 3P+N+PE(three-phase)、50/60 Hz |
| Rated Power | 2×3.5 kW | 2×7 kW | 2×11 kW | 2×22 kW |
Charging Interface
| Dual Type 2 (AC)
Optional：Case A or Case B |
| Rated Voltage | 230 Vac | 400 Vac |
| Rated Current | 2×16 A | 2×32 A | 2×16 A | 2×32 A |
| Power Cable (mm²) | 3×10 | 3×16 | 5×10 | 5×16 |
| Display | 4.3 inch touchscreen |
Charging Mode | Standard：Plug and charge、Card swipe
Optional：QR code scan、APP |
| Networking Mode | Optional: 4G、WIFI、Ethernet |
| Status Indicator | Standby: steady white light; Plug in: steady purple light; Charging: blue breathing light; Charging completed: steady green light; Fault: steady red light |
| Operational Platform | OCPP 1.6J |
| Protection Feature | Overvoltage、Undervoltage、 Overload、 Overtemperature、Lightning protection、Emergency Stop |
| RCD | Type A（30mA）+ 6 mA（DC） |
| Metering Method | MID energy meters |
| Certification | CB、CE |
| Cable Length | 5m (customizable) |
| Dimensions | 345×255×1200 mm (W×D×H) |
| IP Rating | IP 55 |
| Operating Temperature | -30℃～+55℃ |
| Installation Method | Floor-standing |
Fully Customizable to your needs
Fancy another color ? Need your own logo? Didn’t see the feature you need for your operation? No problem. For a full list of current customizations get in touch.
