Dual-Gun Output
Charge two EVs simultaneously

Wide Voltage Range
Supports 200–1000V EVs

Smart Connectivity
4G & Ethernet ensure reliable uptime.

High Efficiency ≥ 96%
Minimize energy loss during charging.

User-Friendly Interface
7-inch LCD touch control panel.

Durable & Weatherproof
IP54 rated for all-climate operation.

Advanced Smart Integration
The 60 kW Dual-Gun DC Charger supports OCPP 1.6J, enabling real-time monitoring, remote diagnostics, and seamless integration with existing charging networks. Operators can manage sessions, analyze performance data, and update firmware remotely — enhancing uptime and operational efficiency. Through RFID, QR code, App, or credit card access, users enjoy multiple secure payment options. This makes it perfect for fleet operators and public charging networks seeking scalable, intelligent EV charging infrastructure.

Robust Design & Reliable Performance
Built for durability and safety, the charger delivers stable power output up to 60 kW with a constant efficiency of ≥ 96%. Its forced-air cooling, industrial-grade components, and comprehensive protections (over/under-voltage, leakage, short circuit, over-temperature) ensure consistent performance in challenging environments. With an operating temperature range of –30 °C to +55 °C and IP54 weatherproof rating, it is engineered for long-term outdoor use in logistics parks, highways, and commercial sites, providing both safety and longevity.
| Model NO. | 60kW Integrated Dual-Gun DC Charger (EU Standard) |
| Input Power Supply | 3P+N+PE(L1、L2、L3、N、PE)、50/60 Hz |
| Input Voltage | 400±10% Vac |
| Rated Power | 60kW |
| Output Voltage | 200~1000 Vdc |
| Constant Power Range | 300~1000 Vdc |
| Maximum Output Current (Imax) | Single gun:200 A;Dual gun:2 x 100 A |
| Rated Input Current | 92 A |
| Power Supply Cable (mm²) | 3x35+2x16 |
| Power Factor | ≥0.99 |
| Peak Efficiency | ≥96% |
| Human-Machine Interface (HMI) | 7-inch LCD Touch Screen |
| Charging Mode | QR Code、RFID Card、APP、Credit Card |
| Network Connectivity | 4G / Ethernet |
| Status Indicator | Green (Standby), Red (Charging), Yellow (Fault) |
| Platform Protocol | OCPP 1.6J |
| Protection Features | Over/Under Voltage, Leakage, Overcurrent, Overtemperature, Short Circuit, Surge, Reverse Protection, Emergency Stop |
| Charging Protocol | DIN70121 / ISO15118 |
| Charging Interface | Dual CCS2 Connectors (EU Standard) |
| Cable Length | ≥4.5 meter |
| Dimensions | Charger:650×350×1400mm(W×D×H) Including Cable Management System:650×350×1600mm(W×D×H) |
| IP Rating | IP54 |
| Operating Temperature | -30℃~+55℃ |
| Relative Humidity | 5%~95% |
| Operating Altitude | ≤2000 m |
| Cooling Method | Forced Air Cooling |
| Installation Method | Floor-mounted Installation |
| Optional | 1、Cable Management System;2、Credit Card; |
Fully Customizable to your needs
Fancy another color ? Need your own logo? Didn’t see the feature you need for your operation? No problem. For a full list of current customizations get in touch.
